Processor(s) (1) Intel® Xeon® E3-1220v3 (3.1GHz/4-core/8MB/80W, HT) Processor
Cache Memory 8MB (1x8MB) Level3
Memory 4GB (1 x 4GB) Unbuffered DIMMs PC3-12800E (1600MHz)
Network Controller HP Ethernet 1Gb 2-port NC332i Adapter
Storage Controller HP Dynamic Smart Array B120i Controller
NOTE: B120i has the following performance with regards to drive speed: 6Gb/s – in 2LFF and 4SFF only with port 0 & 1 installed; 3Gb/s – in 4SFF with more than 2 drives installed. For full 6 Gb.0/s speed a stand up card/smart array controller must be used.
NOTE: B120i supports RAID 0/1/10 only. It does not have FBWC support so cannot support advanced RAID (5 onwards). For FBWC, a standup Smart Array Controller card must be configured.
Hard Drive None ship standard
Internal Storage 2 bay LFF Hot Plug Drive Cage; includes 1 LFF hard drive blank
Optical Drive Bay None ships standard
PCI-Express Slots 1 PCIe3 x16 and 1 PCIe3 x8
Power Supply 300 Watts Non-Hot Plug, Non redundant Power Supply
NOTE: The 300 Watts Non-Hot Plug Non redundant Power Supply is rated at 80% efficiency.
Fans 2 front fan assemblies and 1 center fan assembly ship standard, non-redundant
Management HP iLO Management Engine (standard)
Optional: HP iLO Essentials or HP Insight Control
Form Factor 1U
Warranty Server Warranty includes 1-Year Parts, 1-Year Labor, 1-Year Onsite support with next business day response.
NOTE: No rail kits are included with the server. They must be ordered separately.
