| Processor(s) | (1) Intel® Xeon® E3-1220v3 (3.1GHz/4-core/8MB/80W, HT) Processor |
| Cache Memory | 8MB (1x8MB) Level3 |
| Memory | 4GB (1 x 4GB) Unbuffered DIMMs PC3-12800E (1600MHz) |
| Network Controller | HP Ethernet 1Gb 2-port NC332i Adapter |
| Storage Controller | HP Dynamic Smart Array B120i Controller NOTE: B120i has the following performance with regards to drive speed: 6Gb/s - in 2LFF and 4SFF only with port 0 & 1 installed; 3Gb/s - in 4SFF with more than 2 drives installed. For full 6 Gb.0/s speed a stand up card/smart array controller must be used. NOTE: B120i supports RAID 0/1/10 only. It does not have FBWC support so cannot support advanced RAID (5 onwards). For FBWC, a standup Smart Array Controller card must be configured. |
| Hard Drive | None ship standard |
| Internal Storage | 2 bay LFF Hot Plug Drive Cage; includes 1 LFF hard drive blank |
| Optical Drive Bay | None ships standard |
| PCI-Express Slots | 1 PCIe3 x16 and 1 PCIe3 x8 |
| Power Supply | 300 Watts Non-Hot Plug, Non redundant Power Supply NOTE: The 300 Watts Non-Hot Plug Non redundant Power Supply is rated at 80% efficiency. |
| Fans | 2 front fan assemblies and 1 center fan assembly ship standard, non-redundant |
| Management | HP iLO Management Engine (standard) Optional: HP iLO Essentials or HP Insight Control |
| Form Factor | 1U |
| Warranty | Server Warranty includes 1-Year Parts, 1-Year Labor, 1-Year Onsite support with next business day response. NOTE: No rail kits are included with the server. They must be ordered separately. |
