Lenovo/ IBM System x3250 M5 Server (5458IVA)

Lenovo / IBM System x3100 M5 Server (5457I1C)

Intel xeon E3-1220v3 Processor



Lenovo Server Dealers

RAID - SAS Support

System x3250 M5 server

3 Year warranty

Availability: In stock

Original Lenovo/ IBM System x3250 M5 Server (5458IVA)

  • SERVER - IBM X 3250 M5 5458IVA
  • Intel Xeon E3 (Quad Core), 3.1 Ghz, 8 Mb,1333 Mhz,
  • 1x 4GB,
  • 1x500 GB SATA 7200 RPM 3.5inch Simple-Swap,
  • RAID 01 in built (SR C100),
  • 3 Years Onsite


  • Ground-breaking HDD density in 1U server
  • Flexible, swappable storage options
  • High-performance I/O slots (PCIe)
  • Latest processors & large memory capacity
  • Power-efficient design saves energy costs

System x3250 M5 Features


  • Enhanced performance advantages in a space-saving form factor
  • Improved flexibility for faster, simpler expansion as you need it
  • Entry-level server needs with proven reliability, manageability and value
  • Groundbreaking system storage density in a 1U entry-level server
  • Innovative technology with the latest processors and large memory capacity, in a compact 1U footprint
  • Power-efficient and 80 PLUS®-compliant design to help save energy costs
  • Affordable price point and total cost of ownership

The System x3250 M5 is the most compact rack server in the System x portfolio. Designed in a single-socket 1U form factor, it supports double the system storage density of its predecessor in the same 22-inch deep chassis—four 3.5-inch hard disk drives (HDDs) or up to eight 2.5-inch SAS/SATA HDDs. Choose the latest Intel® processor that best matches your workloads, whether Intel® Xeon® E3-1200 v3 series, Core i3, or Pentium®, including Xeon® Data Center Graphics processors.

 Model dependent.

Simple Upgrades on Demand

After activating the Integrated Management Module 2 (IMM2) standard on your server, you can use Feature on Demand (FoD) for several upgrades. For example, with FoD you can easily enable two more Gigabit Ethernet (GbE) ports, in addition to the two standard ports, without opening your system hardware. You can also upgrade the speed and security of the ServeRAID C100 RAID-5 upgrade within the FoD key activation system. Additionally, by using FoD for upgrades, your two PCIe x8 expansion slots remain free for other upgrade options as your business grows.

More Information
Installation No
Model System x3250 M5
Part No. 5458IVA
Processor Speed 3.1Ghz
Processor Cores Quad Core(4)
Warranty 3 Years Onsite
Hard Drive Bays 2
Form Factor LFF (3.5inch)
Power Wattage 1 fixed 300 W or up to 2 460 W hot-swap redundant
Additional Processor -
DVD Drive No
Network Controller 2 Gbps Ethernet ports standard
Monitor No
Hard Drive 500GB
Operating System No
Processor Intel® Xeon® Processor E3-1220 v3 (8M Cache, 3.10 GHz, 4-core)
Processors Included 1
Cache 8MB
Power Supplies 1
DIMM slots 4
Memory Type DDR 3
Hard Drive Type Hot Plug
RAID Controller Integrated RAID 01 (SR C100)
Remote Console Integrated Management Module 2 (IMM2) standard with IPMI 2.0 and Serial over LAN, optional upgrade to remote presence via FoD; ServerGuide
Processor Sockets 1
System Type Rack
Recommend Entry Level
Memory 4 GB
accessory type Ram
